High-power 12-channel DMX LED driver designed for multi-channel lighting applications, delivering up to 4A per channel and 1152W total output. Features an OLED screen with touch buttons for easy setup and supports DIM, CT, RGB, RGBW and RGBWY modes. Equipped with 5-pin XLR, RJ45, and green terminal DMX interfaces with photoelectric isolation for stable, interference-resistant signal transmission. RDM remote management enables address setting and parameter control, while firmware upgrades, fast self-testing, power-on state management, selectable 8-bit or 16-bit dimming, multiple dimming curves, and comprehensive short-circuit, overcurrent, and overheat protection ensure stable and reliable performance.
- Input voltage: 12~24Vdc
- Current load: 4A × 12CH Max. 48A
- Photoelectric Isolation: Yes
- Working Temperature: -30°C~65°C
- Dimensions: L180 x W122 x H39 (mm)
- Weight: 730g
